UJ-SS625x00 KIT

Click to enlarge photo

Click to enlarge photo

Hide General Information
Part Name:
Stainless Steel - Single Universal Joint
Size Code:
625
Bore Sizing:
Inch
Inch Metric:
Inch
Hide Product Specifications
Part Type:
Single Universal Joint
Part Design:
Stainless Steel
Part Style:
Pin & Block - Friction Bearing
Part Material:
Stainless Steel
Hide Performance Data
Ultimate Torque (in-lbf):
475
Ultimate Torque (Nm):
53.70
Torque Rating (in-lbf):
95
Torque Rating (Nm):
11
Operating_Angle:
45
Hide Dimensional Data
Joint Outside Diameter D (in):
0.63
Joint Outside Diameter D (mm):
15.90
Joint Outside Diameter Nominal D (in):
5/8"
Joint Outside Diameter Nominal D (mm):
n/a
Insp. Hole Location H (in):
n/a
Insp. Hole Location H (mm):
n/a
Overall Length L1 (in):
2.25
Overall Length L1 (mm):
57.20
Yoke Length L2 (in):
1.13
Yoke Length L2 (mm):
28.60
Hub Depth L3 (in):
0.81
Hub Depth L3 (mm):
20.60
Bore diameter B (in):
n/a
Bore diameter B (mm):
n/a
Keyway K (in):
n/a
Keyway K (mm):
n/a
Set Screw:
n/a
Bore Type:
Solid
Bellows:
n/a
Additional info:
KIT. Unassembled - Requires UJ625 TOOL for assembly
